Motherboard chip
Integrated chip Sound card/network card
Main chipset Intel H510
Chipset description Using Intel H510 chipset
Display chip CPU built-in display chip (CPU support required)
Audio chip Integrated Realtek ALC897 7.1 channel sound chip
Network card chip Onboard Intel I219V 1GbE network card
Processor specifications
CPU type 11th/10th generation Core/Pentium/Celeron
CPU slot LGA 1200
Memory specifications
Memory type 2×DDR4 DIMM
Maximum memory capacity 64GB
Memory description Support dual-channel DDR4 3200/3000/2933/2800/2666/2400/2133MHz memory
Storage expansion
PCI-E standard PCI-E 4.0
PCI-E X16 slot 1
PCI-E X1 slot 1
Storage interface 1×M.2 interface, 4×SATA III interface
I/O interface
USB (back panel) 2×USB3.2 Gen1 interface
4×USB2.0 interface
USB (built-in) 2×USB3.2 Gen1 interface
2×USB2.0 interface
Video interface 1×HDMI interface, 1×VGA interface
Power interface One 8-pin, one 24-pin power interface
Other interfaces 1×PS/2 keyboard and mouse universal interface, 1×RJ45 network interface, 3×audio interface

Mingsu

Mingsu H510M m.2 LGA 1200 motherboard

2,199.00 ฿
1,725.00 ฿

Motherboard chip
Integrated chip Sound card/network card
Main chipset Intel H510
Chipset description Using Intel H510 chipset
Display chip CPU built-in display chip (CPU support required)
Audio chip Integrated Realtek ALC897 7.1 channel sound chip
Network card chip Onboard Intel I219V 1GbE network card
Processor specifications
CPU type 11th/10th generation Core/Pentium/Celeron
CPU slot LGA 1200
Memory specifications
Memory type 2×DDR4 DIMM
Maximum memory capacity 64GB
Memory description Support dual-channel DDR4 3200/3000/2933/2800/2666/2400/2133MHz memory
Storage expansion
PCI-E standard PCI-E 4.0
PCI-E X16 slot 1
PCI-E X1 slot 1
Storage interface 1×M.2 interface, 4×SATA III interface
I/O interface
USB (back panel) 2×USB3.2 Gen1 interface
4×USB2.0 interface
USB (built-in) 2×USB3.2 Gen1 interface
2×USB2.0 interface
Video interface 1×HDMI interface, 1×VGA interface
Power interface One 8-pin, one 24-pin power interface
Other interfaces 1×PS/2 keyboard and mouse universal interface, 1×RJ45 network interface, 3×audio interface
2,199.00 ฿
1,725.00 ฿

Mingsu

Mingsu H510M m.2 LGA 1200 motherboard

2,199.00 ฿
1,725.00 ฿
Mingsu H510M m.2 LGA 1200 motherboard

Frequently Bought Together

Total price 7,924.00 ฿

Product Description

Motherboard chip
Integrated chip Sound card/network card
Main chipset Intel H510
Chipset description Using Intel H510 chipset
Display chip CPU built-in display chip (CPU support required)
Audio chip Integrated Realtek ALC897 7.1 channel sound chip
Network card chip Onboard Intel I219V 1GbE network card
Processor specifications
CPU type 11th/10th generation Core/Pentium/Celeron
CPU slot LGA 1200
Memory specifications
Memory type 2×DDR4 DIMM
Maximum memory capacity 64GB
Memory description Support dual-channel DDR4 3200/3000/2933/2800/2666/2400/2133MHz memory
Storage expansion
PCI-E standard PCI-E 4.0
PCI-E X16 slot 1
PCI-E X1 slot 1
Storage interface 1×M.2 interface, 4×SATA III interface
I/O interface
USB (back panel) 2×USB3.2 Gen1 interface
4×USB2.0 interface
USB (built-in) 2×USB3.2 Gen1 interface
2×USB2.0 interface
Video interface 1×HDMI interface, 1×VGA interface
Power interface One 8-pin, one 24-pin power interface
Other interfaces 1×PS/2 keyboard and mouse universal interface, 1×RJ45 network interface, 3×audio interface
